68
–
Standard adjustment
37. Adjusting the safety switch
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the
following work after turning the power o󰀨 and ascertaining that the motor is at rest.
(C) when the presser foot is lifted
(C) when the presser foot is lowered
❷
(B)
Approximately 1 mm clearance
❶
(A)
