JUKI MO-2500 - Adjusting the Floating of the Disk of the Thread Tension Controller

–
44
–
Standard adjustment
25. Adjusting the oating of the disk of the thread tension controller
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the
following work after turning the power o󰀨 and ascertaining that the motor is at rest.
❶
❷
Clearance: 0.9 mm or more
❸
Clearance: 0.9 mm or more
Close contact
❹
❻
❺
❼
❽
When the clearance is too small
When the clearance is too large
