JUKI MO-2500 - Adjusting the Thread Sliding Segment

–
66
–
Standard adjustment
36. Adjusting the thread sliding segment
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the
following work after turning the power o󰀨 and ascertaining that the motor is at rest.
❶
❷
(A) 8 mm or more
❷
Parallel to the throat plate
(B)
(C)
