JUKI MO-2500 - Height and Lateral Position of the Presser Foot

–
38
–
(C)
(B)
Standard adjustment
22. Height and lateral position of the presser foot
(A) 5.8 to 6.0 mm
❶
The presser foot and the
teeth slits have to be in
parallel to each other.
(D)
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the
following work after turning the power o󰀨 and ascertaining that the motor is at rest.
