28
–
17. Radius of the lower looper
Standard adjustment
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the
following work after turning the power o󰀨 and ascertaining that the motor is at rest.
❶
(A) 65.5 ± 0.15 mm
❸
❷
