JUKI MO-2500 - Adjustment of the Loop Lift

–
30
–
Standard adjustment
18. Adjustment of the loop lift
(A)
(B)
(A)
(E)
0 to 0.05 mm
31.58 mm
Gauge needle
❹
❷
❶
❷
❸
❹
(D)
(C)
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the
following work after turning the power o󰀨 and ascertaining that the motor is at rest.
