70
–
Standard adjustment
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the
following work after turning the power o󰀨 and ascertaining that the motor is at rest.
38. Position of the cloth plate
❷
❸
(C) 0.1 to 2.0 mm
(A) 0 to 0.5 mm
(B) 0 to 0.8 mm
❶
(E)
(D)
(F)
❸
