JUKI MO-2500 - Upper Knife Timing Adjustment

–
64
–
Standard adjustment
35. Adjusting the timing of the upper knife
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the
following work after turning the power o󰀨 and ascertaining that the motor is at rest.
❸
❶
❷
(A)
(B)
Screw No. 1
Direction of rotation
<Cross-sectional view
of cam C>
The screw No. 1 faces
perpendicularly upward
when the knife is in its
upper dead point.
