JUKI SC-910N User Manual

– 47 –
E811 Overvoltage • When voltage higher than guaranteed
one is inputted.
• 200V has been inputted to SC-910N of
100V specications.
• JA : 220V is applied to 120V box.
• CE : 400V is applied to 230V box.
• Check whether the applied power voltage is
higher than the rated voltage + (plus) 10% or
more.
• Check whether 100V/200V changeover
connector is improperly set.
In the aforementioned cases, POWER p.c.b is
broken.
E813 Low voltage • When voltage lower than guaranteed
one is inputted.
• 100V has been inputted to SC-910N of
200V specications.
• JA : 120V is applied to 220V box
• Inner circuit is broken by the applied
overvoltage
• Check whether the voltage is lower than the
rated voltage - (minus) 10% or less.
• Check whether 100V/200V changeover
connector is improperly set.
• Ch ec k w he the r fu s e or r eg ene ra t iv e
resistance is broken.
E924 Encoder failure • Motor driver has broken.
E944 R i g h t n e e d l e co n t r o l
impossible
(When LH-4168, or 4188
is selected)
• Right needle has shifted from the origin
during holding it.
• Right needle has shifted from the origin
during releasing left needle.
• Check whether the right needle origin
sensor is broken.
• Check whether needle bar has shifted from
the holding position by the exterior force.
E945 L e f t n e e d l e c o n t r o l
impossible
(WhenLH-4168, or 4188 is
selected)
• Right needle has shifted from the origin
during holding it.
• Right needle has shifted from the origin
during releasing left needle.
• Check whether the left needle origin sensor
is broken.
• Check whether needle bar has shifted from
the holding position by the exterior force
E046 Both-needle lock
(When LH-4168, or 4188
is selected)
• Both needles are locked at the time of
turning ON the power. (Needles are in
the lifting position.)
• Check whether left-right needle position
origin sensors are broken.
• Check whether the sensor connectors are
disconnected or loosely connected.
E730 Encoder failure • When the motor signal is not properly
inputted.
• Check the motor signal connector (CN39)
for loose connection and disconnection.
• Check whether the motor signal cord has
broken since the cord is caught in the
machine head.
E731 Motor hole sensor failure
E303 Woodruff plate sensor error • Woodruff plate sensor signal cannot be
detected.
• C h e c k w h e t h e r t h e m a c h i n e h e a d
corresponds with the machine type setting.
• Check whether the motor encoder connector
is disconnected.
E343 Bobbin thread remaining
amount sensor unit failure
• When the position of the detection bar of
the AE device is shifted from the home
position.
• Check whether the detection bar of the AE
device has returned to the correct position.
• Check whether the function setting No. 57
has been mistakenly set.
• Check the AE device connectors (CN121,
C N 1 2 3 ) f o r l o o s e c o n n e c t i o n a n d
disconnection.
• Check whether the AE device cord has
broken since the cord is caught in the
machine head.
No. Description of error detected Cause of occurrence expected Items to be checked
