Do not change the set values with asterisk (*) mark as they are functions for maintenance. If the standard set value set at the
time of delivery is changed, it is in danger of causing the machine to be broken or the performance to be deteriorated.
If it is necessary to change the set value, please purchase the Engineer’s Manual and follow the instructions.
(Descriptions of setting in this list are the standard values at the time of delivery of DDL-9000A.)
However, contents of function setting are subject to change for improvement of function and performance without notice.
5. Function setting list
No
Item Description
Setting range
Indication of function setting
Ref. page
1 Soft start
function
The number of stitches to be sewn at a low speed when the soft-
start function is used at the start of sewing.
0 : Soft-start function is not operative.
0 to 9
(Stitches)
1 0
31
2 Material end
sensor function
Material end sensor function (used in case of without panel).
0 : Material end detection function is not operative.
1 : After detecting material end, the specified number of
stitches (No. 4) will be sewn, and the sewing machine will
stop.
0/1
2 0
3
Thread trimming
function by
material end
sensor
Thread trimming function by material end sensor (used in case
of without panel).
0 : Automatic thread trimming function after detection of ma-
terial end is not operative.
1 : After detecting material end, the specified number of
stitches (No. 4) will be sewn, and the sewing machine will
stop and perform automatic thread trimming.
0/1
3 0
4 Number of
stitches for
material end
sensor
Number of stitches for material end sensor (used in case of with-
out panel).
Number of stitches from detection of material end to stop of the
sewing machine.
0 to 19
(Stitches)
4 5
5 Flicker reducing
function
Flicker reducing function (If the hand lamp ickers).
0 : Flicker reducing function is not operative.
1 : Less effective
/
8 : Highly effective
0 to 8
5 0
31
6 Bobbin thread
counting
function
Bobbin thread counting function
0 : Bobbin thread counting function is not operative.
1 : Bobbin thread counting function is operative.
0/1
6 1
31
*
7 Unit of bobbin
thread counting
down
Unit of bobbin thread counting down
0 : Count/10 stitches
1 : Count/15 stitches
2 : Count/20 stitches
0 to 2
7 0
*
8 Number of
rotation of
reverse feed
stitching
Sewing speed of reverse feed stitching
150 to 3,000
(r.p.m.)
8 1 9 0 0
9 Thread
trimming
prohibiting
function
Thread trimming prohibiting function (used in case of without panel).
0 : Thread trimming prohibiting function is not operative.
1 : Thread trimming is prohibited.
(Output of solenoid is prohibited. : Thread trimmer and wiper)
0/1
9 0
31
10 Setting of
needle bar stop
position when
the sewing
machine stops.
Position of needle bar is specified when the sewing machine
stops.
0 : Predetermined lowest position
1 : Predetermined highest position
0/1
1 0 0
31
11 Click sound
of key switch
mounted on
PSC
Click sound of key switch mounted on PSC is specied.
0 : Click is not operative.
1 : Click is operative.
0/1
1 1 1
31
12 Optinal switch
function
selection
Switching of function of optional switch.
0 : No function
1 : Needle up/down compensating stitching
2 : Back compensating stitching
3 : Function of canceling once reverse feed stitching at the
end of sewing
4 : Thread trimming function
5 : Presser foot lifting function
6 : One stitch compensating stitching
7 : Function of simultaneously canceling reverse feed stitch-
ing at the start and end of sewing
8 : Function of neutral presser foot lifting changeover
0 to 8
1 2 0
32
*
13 Function of
prohibiting start
of the sewing
machine by
bobbin thread
counter
Function of prohibiting start of the sewing machine by bobbin thread counting
0 : When counting is out (-1 or less) Function of prohibiting
start of the sewing machine is not operative.
1 : When counting is out (-1 or less) Function of prohibiting
start of the sewing machine after thread trimming is op-
erative.
2 : When counting is out (-1 or less), the sewing machine
stops once. Function of prohibiting start of the sewing
machine after thread trimming is operative.
0 to 2
1 3 0
14 Sewing counter Counting function of sewing (number of completion of process)
0 : Sewing counter function is not operative.
1 : Sewing counter function is operative.
0/1
1 4 1
32
*
15
Number of times
of detection of
run-out of bobbin
thread remaining
amount
Number of times of detection of run-out of bobbin thread remain-
ing amount
0 : Function of bobbin thread remaining amount is not
operative.
1 to 19 : Number of times during which the signal is not made
even if run-out of bobbin thread remaining amount is
detected.
0 to 19
1 5 1
To Next Page
