JUMO dTRANS p02 - 1 Typographical Conventions; 2 General; 3 Delivery Package; 4 Instrument Identification

Contents
1 Typographical conventions __________________________ 4
1.1 Warnings ____________________________________________________ 4
1.2 Note signs ___________________________________________________ 4
2 General ____________________________________________ 5
2.1 Preface _____________________________________________________ 5
2.2 Application __________________________________________________ 6
3 Delivery package ___________________________________ 7
4 Instrument identification _____________________________ 8
4.1 Nameplate __________________________________________________ 8
4.2 Type designation _____________________________________________ 9
4.3 Dimensions/details __________________________________________ 10
4.4 Dimensions: "non-flush pressure connections" __________________ 10
4.5 Dimensions: "flush pressure connections" ______________________ 11
5 Instrument description _____________________________ 12
5.1 Technical data _____________________________________________ 12
6 Mounting __________________________________________ 14
6.1 General ____________________________________________________ 14
6.2 Prior to mounting ____________________________________________ 14
6.3 Mounting by the pressure connection __________________________ 15
6.4 Mounting by the housing _____________________________________ 15
6.5 Pressure connection _________________________________________ 16
6.6 Use inside the Ex area _______________________________________ 16
7 Installation ________________________________________ 17
7.1 Electrical connection _________________________________________ 17
7.2 Testing the output signal _____________________________________ 19
7.3 Connection of a HART
®
modem ______________________________ 19
7.4 Connection of a HART® communicator ________________________ 20
7.5 Testing the HART
®
communication ____________________________ 20
7.6 Electrical connection in the hazardous (Ex) area _________________ 21
