JUMO dTRANS p02 - Application

2 General
6
2.2 Application
General The type JUMO dTRANS p02 is used to measure the pressure of corrosive
and non-corrosive gases, vapors and liquids. The pressure transmitter uses
the piezo-resistive effect to make the measurement. The output signal is a pro-
portional DC current which is linearly proportional to the input pressure.
Version with
Ex protection
The JUMO dTRANS p02 pressure transmitter in intrinsically safe version
marked II 1/2 G EEx ia IIC T6, is suitable for mounting within the hazardous
area Zone 1 for connection to Zone 0.
The EC Type-Examination Certificate for the JUMO dTRANS p02 is:
PTB 98 ATEX 2194
If this pressure transmitter is used in areas with potentially explosive atmo-
spheres, the appropriate regulations for installing and operating equipment in
such areas must be observed.
The diaphragms of the JUMO dTRANS p02 pressure transmitter
must not be damaged. Do not insert any objects into the bores of
the pressure connections!
