JUMO dTRANS T02 LCD - Installation; Connection Diagram; Power Supply Connection

4
2 Installation
Connection diagram
Connection for
Supply as per nameplate
Analog inputs
Thermocouple
Resistance thermometer
in 2-wire circuit
R
L
≤ 30Ω (R
L
= total lead resistance)
Resistance thermometer
in 3-wire circuit
Resistance thermometer
in 4-wire circuit
Setup interface
Please refer to “Setup
interface” on page 8
R
L
R
A
R =R
AL
21345
!
21345
!
21345
!
