JUMO dTRANS T02 LCD - Overview of Operation; Parameter Level; Configuration Level

Overview of operation
Normal display
- measurement display
q > 2s
Parameter level
- Limit for limit comparator 1 AL1
- Limit for limit comparator 2
- Fine calibration 0%
- Fine calibration 100 %
- Teach-in
Al2
OUtL
OUtH
OFFS
q
Configuration level
- Probe type
- Linearization
- Number of decimal places
- Unit of measurement
- Supply frequency and
temp. compensation
- TC fixed value
- Measurement display
- Function of analog output
- Signal on probe break
- Logic output 1
- Signal on probe break/short-circuit
- Lower differential
- Upper differential
- Logic output 2
- Signal on probe break
- Lower differential
- Upper differential
- Frequency at range start
- Frequency at range end
- Scaling start value
- Scaling end value
- Filter time constant
- Total resistance for res. transmitter
- Simulation of measurement output
C111
C112
C113
C002
C114
C115
C116
C211
C212
C221
C222
C223
C224
C231
C232
C233
C234
C235
C236
SCL
SCH
DF
R FE
C001
-
/short-circuit
/short-circuit
q
q > 2sec
q > 2sec
q after last parameter
qdTime-out (20sec) or +
q after last parameter
H
H
In order to make the settings, you have to exit the parameter level via the parameter OFFS. Otherwise, the parameter values of the configuration level can only be viewed.
