18
4 Functions and operation
Frequency output
If the parameter C231 is set to the value 3, the measurement signal
is output as a frequency at the terminals of the open-collector out-
put 2 (parallel to the current/voltage output). The limits of the fre-
quency range are determined by the parameters C235 and C236.
T
open collector 2
active
inactive
t
