5 Configuration and parameter tables
You can record your settings in the configuration and parameter ta-
bles below, in the position (column) marked with . The factory
settings are shown on a gray background ( ).
Parameters at the parameter level
Parameters at the configuration level
Measurement input
Para-
meter
Explanation Value range factory
setting
X
Al1 Limit value of
limit comparator 1
-1999 to
+9999 digit
0
AL 2 Limit value of
limit comparator 2
-1999 to
+9999 digit
0
OUTL Fine calibration 0%
(zero)
see “Fine calibration (zero point
and full scale)” on page 19
OuTH Fine calibration 100%
(full scale)
see “Fine calibration (zero point
and full scale)” on page 19
OFFS Teach-in see “Teach-in” on page 20
C111 Transducer
X
0Resistance thermometer in 3-wire circuit
1 Resistance thermometer in 4-wire circuit
2Resistance thermometer in 2-wire circuit
3Thermocouple
4Voltage up to 1000mV
5Voltage up to 10V
6Current
7Resistance transmitter
8Potentiometer 3-wire circuit
9Potentiometer 4-wire circuit
10 Potentiometer 2-wire circuit
