Page #14 background image
B 5
0205.GB
3 Standard Version Specifications
Z
Technical data specified in accordance with VDI 2198.
Technical modifications and additions reserved.
3.1 Performance data for standard trucks
*) With longer fork versions the load centre of gravity is in the centre of the forks
3.2 Dimensions
* Load section raised / lowered +55 mm
** Diagonal in accordance with VDI +204 mm
Description EJD K18
Q Capacity 1800 kg
C Load centre of gravity distance 600 mm
Travel speed
with / without load
5,79 / 5,98 km/h
Lift speed
w / w.o. load
12 / 22 cm/s
Lowering speed
w / w.o. load
24 / 17 cm/s
Max. gradeability (5 min rating)
with / without load
6 / 12 %
Description EJD K18
Short version/
Long version
h
1
Mast height (retracted) 1295 mm
h
3
Lift 1660 mm
h
4
Mast height (extended) 2250 mm
h
5
Initial lift 125 mm
h
13
Load handler lowered 90 mm
Y* Wheel base (short / long) 1365 / 1435 mm
l
1
Overall length (short / long) 1840 / 1910 mm
l
2
Length including fork shank (short, long) 650 / 720 mm
l Standard fork length 1190 mm
b
1
Truck width 700 mm
b
4
Width within forks 170 mm
b
5
Width across forks 550 mm
e Fork width 190 mm
Wa* Turning radius 1475 mm
Ast* Aisle width for pallets 800 x 1200 length 2197** / 2267** mm
Ast* Aisle width for pallets 1000x1200 traverse 2290 / 2360 mm
