2 Controls and Displays

Item Control / Display EJD 118 Function

1 Key switch t Switches control current on and off.

Removing the key prevents the truck

from being switched on by

unauthorised personnel.

Key switch with second

switch level

o Releases the brakes to move the truck

when non-operational.

2 Discharge monitor t Battery charge status.

Display instrument

(CANDIS)

o Operating hours meter.

Battery charge status.

Displays service messages and travel

parameters in combination with

CANCODE.

3 Keypad

(CANCODE)

o Code settings.

Release and select the travel

programs.

Enter travel parameters.

4 Integrated charger

(including safety switch)

o Charges the battery by inserting the

mains connector in a mains socket.

5 Tiller t Used to steer and brake the truck.

6 Crawl button t Pressing the crawl button reduces the

travel speed and acceleration. If the

tiller is set to the brake zone, you can

press this button to override braking;

the truck will travel at slow speed .

7 Lower button t Lower load handler.

8 Raise button t Raise load handler.

9 Travel switch t Controls travel direction and speed.

10 Collision safety switch t Truck moves away from operator.

11 Outrigger lift button t Raise outriggers.

12 Outrigger lower button t Lower outriggers.

13 Warning button t Activates an audible signal.

14 Battery connector

(emergency disconnect)

t Interrupts the circuit, all electrical

functions are cut out.

t = Standard equipment o = Optional Equipment
