0307.GB
F 10
6.5 Checking electrical fuses
– Preparing the truck for maintenance and repairs
(see Section 6.1).
– Remove the front panel
(see Section 6.2).
– Check all fuse ratings in accordance with the table; replace if necessary.
Item Description To protect: Rating
7 F10 On board charger (option) 10 A
8 F1 Overall control fuse 10 A (T)
9 1F1 Traction motor 100 A
10 2F1 Pump motor 100 A
10
9
0307.GB
F 10
6.5 Checking electrical fuses
– Preparing the truck for maintenance and repairs
(see Section 6.1).
– Remove the front panel
(see Section 6.2).
– Check all fuse ratings in accordance with the table; replace if necessary.
Item Description To protect: Rating
7 F10 On board charger (option) 10 A
8 F1 Overall control fuse 10 A (T)
9 1F1 Traction motor 100 A
10 2F1 Pump motor 100 A
10
9
