Jungheinrich EKS 310 User Manual

0504.GB
D 4
– Undo and remove the battery retainers (5;7).
– Pull the battery (6) onto the side of the prepared battery transporter.
Assembly is the reverse order.
F
After installing again, check all cables and connectors for signs of visible damage and
before using the truck again check that:
– the battery retainers are inserted and secured,
– the battery cover is properly closed.
6
5
7
0504.GB
D 4
– Undo and remove the battery retainers (5;7).
– Pull the battery (6) onto the side of the prepared battery transporter.
Assembly is the reverse order.
F
After installing again, check all cables and connectors for signs of visible damage and
before using the truck again check that:
– the battery retainers are inserted and secured,
– the battery cover is properly closed.
6
5
7

Jungheinrich EKS 310 Specifications

General

Brand	Jungheinrich
Model	EKS 310
Category	Forklifts
Language	English
