E 9
0206.GB
3.3 Truck operational status symbols
The operational status of the truck when it has been switched on is indicated by
symbols in the display unit.
Safety gates open
Foot switch not pressed
Attachment in home position
When the following symbols are displayed you must carry out a reference movement
in accordance with the display, i.e. the Main Lift must be raised approx. 10 cm and
lowered again. This is the only way for the controller to release all the truck
movements at full speed.
E 9
0206.GB
3.3 Truck operational status symbols
The operational status of the truck when it has been switched on is indicated by
symbols in the display unit.
Safety gates open
Foot switch not pressed
Attachment in home position
When the following symbols are displayed you must carry out a reference movement
in accordance with the display, i.e. the Main Lift must be raised approx. 10 cm and
lowered again. This is the only way for the controller to release all the truck
movements at full speed.
