Design
The HC 110 is a four-wheel truck with two steered wheels (9) and two load
wheels (6). The electrical components and the hydraulic unit are located under the
front cover (7).
Controls and displays
The lift and lower controls are arranged on the front panel.
The truck is equipped with a battery discharge indicator.
Steering
The tiller (11) is used to steer within a range of approx. 90° on either side.
Brake system
The parking brake is actuated via the brake pedal (8).
Hydraulic system
Lifting and lowering are applied via the lift and lower buttons. The pump unit starts
with lifting is activated. The hydraulic oil is pumped from the oil reservoir into the
cylinder. The forks (5) are raised.
Electrical system
12 volt system.
3 Technical Specifications
Z
The technical specification is given according to the German guideline "Type sheets
for industrial trucks". Technical modifications and additions reserved.
3.1 Performance data
HC 110
Q Rated capacity 1000 kg
c Load centre distance for standard fork
length *)
600 mm
Lift speed with / without load 90 / 140 mm/s
Lower speed with / without load 120 / 100 mm/s
*) For trucks with longer forks the load centre is in the centre of the fork.
14
04.16 en-GB
