Jungheinrich HC 110 User Manual

3.2 Dimensions
A
st
W
a
a/2 = 100 a/2 = 100
b
11
h
1
l
2
l
1
h
13
h
3
h
4
l
c
Q
y
s
h
14
min.
951
b
1
b
10
b
5
e
h
14
max.
Model
Lift height
HC 110
1600
HC 110
2500
HC 110
3000
h
1
Mast height retracted
1980 1830 2080 mm
h
3
Lift
1600
2500 3000 mm
h
4
Mast height extended 1980
3070
3570
mm
h
13
Ground clearance
below mast
85 85 85 mm
y Wheel distance 1160 1160 1160 mm
s/e/l Fork dimensions 60/180/1100 60/180/1100 60/180/1100 mm
l
1
Overall length 1720
1720 1720
mm
15
