Starting to charge with the on-board charger
Mains connection
Mains supply: 230 V (+/-10%)
Mains frequency: 50 Hz (+/-10%)
The mains cable (34) of the charger is contained
in the front panel.
Charging the battery
Requirements
– Park the truck securely, see page 41.
Procedure
• Attach the mains connector (34) to a mains
socket.
• Pull the Emergency Disconnect switch (3) up.
The flashing LED indicates the charge
status (33) or a fault (for flashing codes see
“LED Display” table).
The battery is now charged.
LED displays (33) battery charger
LED Meaning
Red Battery is almost empty and must be charged.
Yellow Battery is almost charged, 80% charge capacity reached.
Green Battery is fully charged.
30
04.16 en-GB
