Juniper EX4100

Table 38: RJ-45 to DB-9 Serial Port Adapter Pinout Informaon
RJ-45 pin Signal DB-9 pin Signal
1 RTS 8 CTS
2 DTR 6 DSR
3 TxD 2 RxD
4, 5 GND 5 GND
6 RxD 3 TxD
7 DSR 4 DTR
8 CTS 7 RTS
NOTE: The RJ-45 to DB-9 adapter supplied in the package, does not have DCD pin. Hence,
logout-on-disconnect feature will not work when this parcular connector is used.
