Juniper EX4100

Table 3: Physical Specicaons of the EX4100 and EX4100-F Switch Chassis (Connued)
Model Chassis Height Chassis Depth Chassis Weight with
Power Supply and
Fan Module
With no power
supply and fan
module
With power supply
and fan module
installed
EX4100-24T 1.72 in (4.37 cm) 13.18 in (35 cm) 14.87 in (37.76 cm) 5875g
EX4100-48P 1.72 in (4.37 cm) 13.18 in (35 cm) 14.87 in (37.76 cm) 6495g
EX4100-48T 1.72 in (4.37 cm) 13.18 in (35 cm) 14.87 in (37.76 cm) 6010g
EX4100-F-24T 1.72 in (4.37 cm) NA 10.1 in (25.65 cm) 3520g
EX4100-F-24P 1.72 in (4.37 cm) NA 12.2 in (31.13 cm) 4745g
EX4100-F-48P 1.72 in (4.37 cm) NA 12.2 in (31.13 cm) 5200g
EX4100-F-48T 1.72 in (4.37 cm) NA 10.1 in (25.65 cm) 3885g
Table 4: Weight of Fan Module and Power Supply
Model Fan Module Weight Power Supply Unit Weight
AFO Fan FRU AFI Fan FRU 920W AC 150W AC 150W DC
EX4100-24MP
and
EX4100-48MP
73g 73g 846g NA NA
37
