Page 72
Appendix A: Group Simultaneous Pulse Feature
© JVA Technologies www.jva-fence.com JVA Z13 Manual
total)
Key3 Mode
0 No Group
1 Master
2 Slave 1
3 Slave 2
4 Slave 3
5 Slave 4
6 Slave 5
7 Slave 6
8 Slave 7
9 Slave 8
10 Slave 9
11 Slave 10
12 Slave 11
13 Slave 12
14 Slave 13
15 Slave 14
14.3
The keypad terminals on all Energizers in the group are linked. Since only
one Energizer needs to power the keypad, 3 wires are linked from one En-
-
ery other Energizer in the group. Do not connect the + lines between Ener-
gizers as this could result in some strange behaviour and possibly damage.
possible for a PC to be added to the group using a keypad to USB adaptor
(PAE223).
