Advanced Operations
VPos Alignment
Sometimes the vertical position indicator at screen left border is
not aligned with 0V level trace. This can be fixed by
performing VPos Alignment. To do this touch “Menu” at
top-left screen corner to bring up menu page and select the
button “VPos Cal”.
Save Waveform
Captured waveform can be saved to in-chip EEPROM so as it
is retained after power down and can be recalled at a later time
for reviewing. To do this enter Menu and touch the button
“Save WF”. The most recently captured and displayed
waveform before entering Menu will be saved. The associated
scope parameters are also saved at the same time.
In order to make sure the right waveform is saved it is
suggested to hold a waveform before saving it.
Please note that saving a waveform will overwrite the data
already in EEPROM without warning. That is to say, the
previously saved waveform will be lost when a new waveform
is saved.
Recall Waveform
Saved waveform can be recalled and displayed on screen
without any change. To do this enter Menu and touch the button
“Recall WF”. Recalled waveform is always displayed in HOLD
state.
