Weight
80 grams (probe not included)
Appendix A: Coded Values of Oscilloscope Parameters
1) Values of Timebase
Setting Values
50s/div
0x07
20s/div
0x08
10s/div
0x09
5s/div
0x0A
2s/div
0x0B
1s/div
0x0C
0.5s/div
0x0D
0.2s/div
0x0E
0.1s/div
0x0F
50ms/div
0x10
20ms/div
0x11
10ms/div
0x12
5ms/div
0x13
2ms/div
0x14
1ms/div
0x15
0.5ms/div
0x16
0.2ms/div
0x17
0.1ms/div
0x18
50us/div
0x19
20us/div
0x1A
10us/div
0x1B
5us/div
0x1C
2us/div
0x1E
1us/div
0x1E
2) Values of Trigger Mode
Setting Values
Auto
0x00
Normal
0x01
Single
0x02
3) Values of Trigger Slope
Setting Values
Falling
0x00
Rising
0x01
