DN112-06v02
JYE Tech - 30 - www.jyetech.com
J11: This connector is for alternative UART. It is a LVTTL
connection.
Pin#
Signal
Name
I/O
1 TXD Output
2 RXD Input
3 GND
4 +3.3V
Dimensions
Unit: mm
