Kaba Access manager 92 32 User Manual

Product Description Technical Manual
12 04045524 - 08/2016 Kaba access manager 92 32
The power specification refers to the contact loading capacity of the relay. The
actual available power depends on the power of the external power supply unit.
3.3.4 Outputs
3 relay outputs
• OUT1: Switches one of the following power sources to the terminal
(can be selected via jumper):
– 12 V DC
– 24 V DC (external device power supply)
– External relay voltage (can be fed in via the terminals)
• OUT2 + OUT3: Potential-free change-over contact
• Contact rating: 30 V AC/DC; 2 A max.
• LED status display
3.3.5 Inputs
4 digital inputs
• With integrated power supply and common ground to connect potential-free
contacts.
• Optional line monitoring
• LED status display
Tamper
• Switching contact for removal of the housing cover
• Switching contact for removal of the device from the wall (bridge using jumper)
3.3.6 Interfaces
Ethernet interface
• IEEE802.3 compatible 10BASE-T/100BASE-TX /1000BASE-T Auto sensing, Auto
MDIX.
RS-232
• Serial interface for specific applications
• Transmission parameters can be set via the terminal software.
HF-RFID
• 2 registration units with or without PIN keypad (connections Ant. A and Ant. B)
• Coaxial cable, impedance 50 Ohm
• Encrypted data transmission
Wiegand
• The Wiegand 1 + 2 interfaces are not supported at the moment
RS-485
• The RS-485 interface is not supported at the moment
