5.7.6.6 Status display
Below the terminals for the outputs, there are light emitting diodes for status display
of the outputs.
The current status of the outputs is indicated as follows.
Designation Signal Meaning
REL1-3 Off Relay is not pulled-in
lit green Relay is pulled-in
