KAESER CSD series User Manual

Technical Specification
2 --- 8
CSD 122CSD 102CSD 82
Power consumption [A] (option K1) 154 189 ---
Power consumption [A] (option K2) 151 185 ---
Tab. 15 Power supply details 230V/3/50Hz
Rated power supply 400V
 10%, 3---ph, 50Hz
CSD 82 CSD 102 CSD 122
Mains fuses [A] 100 125 160
Supply cable [mm
2
] 4 x 35 4 x 50 4 x 70
Power consumption [A] (option K1) 89 108 139
Power consumption [A] (option K2) 87 107 136
Tab. 16 Power supply details 400V/3/50Hz
Rated power supply 230V

10%, 3---ph, 60Hz
CSD 82 CSD 102 CSD 122
Mains fuses [A] 200 224 ---
Supply cable [mm
2
] 4 x 95 4 x 120 ---
Power consumption [A] (option K1) 160 191 ---
Power consumption [A] (option K2) 151 185 ---
Tab. 17 Power supply details 230V/3/60Hz
Rated power supply 380V

10%, 3---ph, 60Hz
CSD 82 CSD 102 CSD 122
Mains fuses [A] 125 125 160
Supply cable [mm
2
] 4 x 50 4 x 50 4 x 70
Power consumption [A] (option K1) 99 114 148
Power consumption [A] (option K2) 97 112 145
Tab. 18 Power supply details 380V/3/60Hz
Rated power supply 440V
 10%, 3---ph, 60Hz
CSD 82 CSD 102 CSD 122
Mains fuses [A] 100 125 160
Supply cable [mm
2
] 4 x 35 4 x 50 4 x 70
Power consumption [A] (option K1) 84 102 124
Power consumption [A] (option K2) 82 100 122
Tab. 19 Power supply details 440V/3/60Hz
Rated power supply 460V

10%, 3---ph, 60Hz
CSD 82 CSD 102 CSD 122
Mains fuses [A] 100 125 160
Supply cable [mm
2
] 4 x 35 4 x 50 4 x 70
Power consumption [A] (option K1) 80 97 119
Power consumption [A] (option K2) 79 95 117
Tab. 20 Power supply details 460V/3/60Hz

KAESER CSD series Specifications

General

Series	CSD
Type	Rotary Screw Compressor
Drive Type	Direct Drive
Cooling	Air
Motor Efficiency	IE3
Free Air Delivery	0.5 to 4.5 m³/min
Working Pressure	7.5 to 15 bar
Drive	Direct
