KAESER CSD series User Manual

Technical Specification
2 --- 9
2.10 Water cooling (option K2)
2.10.1 Design data
Cooling water temperature rise 10 K
CSD 82 CSD 102 CSD 122
Max. permissible inlet temperature
[˚ C]
40 40 40
Cooling water volume [m
3
/h] 4.4 5.4 6.3
Water pressure drop [bar] 1.2 1.7 2.4
Tab. 21 Water cooling design data (10 K)
Cooling water temperature rise 30 K
CSD 82 CSD 102 CSD 122
Max. permissible inlet temperature
[

C]
20 20 20
Cooling water volume [m
3
/h] 1.5 1.8 2.1
Water pressure drop [bar] 0.5 0.5 0.5
Tab. 22 Water cooling design data (30 K)
Cooler specification
Material of manufacture
1.4401
Solder Copper
Maximum working pressure (cooling
water end) [bar]
10
UNsuitable cooling medium Seawater
Consult Kaeser before using cooling water solu-
tions
Max. permissible discharge tempera-
ture [˚ C]
70
Tab. 23 Cooler specification; water cooling
2.10.2 Cooling Water Quality
Do not use the cooling water as drinking water.
If a leak occurs, oil can contaminate the cooling water.
It is imperative that measures for cooling water treatment and filtration are carried out.
The addresses of companies specialising in cooling water analysis and the supply of suit-
able equipment for its treatment can be obtained from KAESER.
To avoid operational breakdowns caused by a corroded or clogged cooler, the cooling
water must meet the following requirements:
pH value
7.5 to 9
Hardness [ dH] 4,0---8,5
Chloride (Cl) [mg/l] < 150
Free chlorine gas (Cl
2
) [mg/l] < 1
Sulphate (SO
3
) [mg/l] < 1
