KAESER CSD series - Cooler Maintenance; Air Cooling (Option K1); Filter Mat Maintenance (Option K3)

Maintenance
10 --- 56
10.3 Cooler Maintenance
10.3.1 Air cooling (option K1)
Material: brush
vacuum cleaner
Pre---condition: Machine switched off.
Mains isolator locked off
Machine cooled down.
Check the cooler regularly for contamination. Frequency is mainly dependant on local op-
erating conditions.
Contamination causes overheating and machine damage.
Avoid dust disturbance. Wear breathing apparatus if necessary.
Do not use sharp objects to clean the cooler. The cooler could be damaged.
A severely contaminated cooler should be cleaned by a KAESER service agent.
Fig. 20 Cleaning the cooler
1 Cooler
2 Brush

Dry brush the cooler (1) and use a vacuum cleaner to suck up the dirt.
10.3.2 Filter mat maintenance (option K3)
Material: Warm water and household detergent
Spare parts (as required)
Pre---condition: Machine switched off.
Mains isolator locked off
Machine cooled down.
