8 Replace the gasket if damage is present or it is removed from
the groove in the rocker lever cover.
•
Press the molded gasket into the corners of the rocker
lever cover.
•
Press the rest of the gasket into the rocker lever cover.
9 Examine the rubber isolators for cracks.
10 Replace if cracked or broken.
Adjust
1 Engine coolant temperature must be less than 60°C (140°F).
Use the barring tool to rotate the crankshaft until the number 1
cylinder is at top-dead center (TDC).
2 The TDC indicator is on the vibration damper.
Align the vibration damper so the TDC indicator is at the 12
o'clock position.
If both of the number 1 cylinder rocker levers are loose, pro‐
ceed to the next step; If the number 1 cylinder rocker levers
are not loose, rotate the crankshaft 360 degrees and proceed
to the next step.
