Kane 457 - Performing a Pressure Test

Page 21
PRESSURE TEST
Select “Prs”. The pump stops automatically. Press / to auto-zero the
pressure sensor. Do this before you connect to anything. Using the black connectors and
manometer hose, connect to P1 for single pressure or P1 and P2 for differential pressure.
PRS display
PRESSURE
→
Normal response or smoothed (damped)
response can be selected via “Menu”.
P 0.01
→
‘High’ or ‘Low’ resolution readings can be
selected via “Menu”.
mbar
→
Pressure units can be selected via “Menu”.
14:56:29
→
Displays time to enable manually timed tests.
Press / to print a full pressure test, (or send to PC via optional Wireless
module).
Hold / for 2+ seconds to log a pressure report.
Viewing / printing a logged pressure test
Select MENU / REPORT / PRESSURE / VIEW
Use or to select the log number to be printed.
Press / to print the test, (or send to PC via optional Wireless module).
Before the 21
st
pressure test can be logged this section of the memory must be
cleared. Make sure you print off any results that you need before actioning the
DELETE ALL .
