Page 26
DIFFERENTIAL TEMPERATURE
Select “Diff Temp” to measure flow, return and differential temperatures
DIFF TEMP display
TEMP
→
Pump stops automatically when dial is moved
to Diff Temp.
T1c 60.4
→
Use the T1 connection for the flow
temperature sensor.
T2c 55.2
→
Use the T2 connection for the return
temperature sensor.
∆Tc 5.2
→
Real time temperature difference.
Press / to print a differential temperature test, (or send to PC via
optional Wireless module).
Hold / for 2+ seconds to log a differential temperature report.
Viewing / printing a differential temperature test
Select MENU / REPORT / TEMP / VIEW
Use or to select the log number to be printed.
Press / to print the test, (or send to PC via optional Wireless module).
Before the 21
st
temperature test can be logged this section of the memory must
be cleared. Make sure you print off any results that you need before actioning
the DELETE ALL .
