NOTICE

Damage to the CEU and/or CSU due to usage of not recommended cables or not

authorized CEU/CSU components!

If cables/plugs other than those recommended by Kappa are used, or authorized

CEU/CSU components, the electrical connectors of the CEU/CSU or the units

themselves can be damaged.

 Make sure that you use only the recommended cable/plugs and authorized

CEU/CSU components (Refer to 6.2).

 For smart wire/passive wire: The cable connections to the plug must additionally

be protected with shrink tubes to ensure, that no humidity can enter.

Figure 4-2 Example Flight Eye FE320 Kit – Direct connection – no wire – 370-0399 – 962-0102
