Connections
NOTICE
To make sure that the equipment function without failure, strictly follow the
manufacturer’s instructions regarding solder, crimp and mechanical endurance.
 Kappa is not liable for any misuse.
Power Supply Connector A2 - CEU
The power is supplied by an external power supply unit, connected to the 3-pin connector
“Souriau 8 STA 20235 PN” on the rear side of the CEU (Figure 4-9).
Connector type:
8 STA 20235 PN
View from outer side of CEU:
Description:
Power Connector A2
Kappa PN:
332-0311
Recommended cable connector
8STA60235SN
Kappa PN: 332-0313
Recommended cable
Kappa PN: 922-0287
Table 4-2 Power supply connector A2 – CEU
