Family Setups
Different combinations of CSU and CEU and interface-connections are possible. There are two different
heads of the CSU: for Rolling Shutter or Global Shutter. The possible configurations are then increased by
different optics, which can be installed into the two CSU-heads.
Refer to the Figures 4-3 thru 4-5 for different family setups.
CEU FE320 GV 28V (962-0102)
CSU
IMX236 41°
(370-0399)
Figure 4-3 Family setup 1
Figure 4-4 Family setup 2
CEU FE320 GV 28V (962-0102)
CSU
IMX252 51°
(370-0413)
Smart Wire
(370-0417)
Figure 4-5 Family setup 3
