Kappa Flight Eye FE320 - Table 4-5 M2-Pin Configuration CEU

23
4.5.2.1 Pinning Communication Connector M2
Pin
Signal
I/O
Comment
Colour
according
to
EIA/TIA
568B
Use for
1000BaseT
Use for
100BaseT
1
GigE_Cp
Input /
Output
GigE Pair C
Blue
Yes
No
2
GigE_Shield
--
GigE Shield
-
Yes
Yes
3
GigE_Bn
Input /
Output
GigE Pair B
Green
Yes
Yes
4
GigE_An
Input /
Output
GigE Pair A
Orange
Yes
Yes
5
GigE_Cn
Input /
Output
GigE Pair C
White /
Blue
Yes
No
6
GigE_Dn
Input /
Output
GigE Pair D
Brown
Yes
No
7
GigE_Bp
Input /
Output
GigE Pair B
White /
Green
Yes
Yes
8
GigE_Ap
Input /
Output
GigE Pair A
White /
Orange
Yes
Yes
9
GigE_Shield
--
GigE Shield
-
Yes
Yes
10
GigE_Dp
Input /
Output
GigE Pair D
White /
Brown
Yes
No
11
TRIGGER_IN_ISO
Input
Isolated Trigger Input
3.5 – 5.5V DC High Level,
< 0.4 VDC Low Level
12
GND_ISO
--
Isolated Trigger Reference
13
STROBE_OUT_ISO
Output
Isolated Trigger Output
4.75 – 5V DC High Level,
< 0.4 VDC Low Level
Table 4-5 M2-Pin Configuration CEU
