EN
10 762.885 Z05 2012 coolcept_fleX, coolcept³_fleX
4 Description
4.1 Scope of delivery
Inverter
Mounting plate
AC plug (coolcept fleX: 3-pin, coolcept³ fleX: 5-pin)
DC plug (one pair*)
Sealing cap (3 units)
Installation and operating instructions
* coolcept fleX 3011_2, 3611_2, 4611_2 and 5011_2: two pairs
4.2 Structure of the device
Case
Display (monochrome, 128 x 64 pixels)
Operating buttons (for function refer to chapter 8)
Connections
