Inverter, 1 phase
Cable cross section
AC cable
Power loss
(with 10 m cable length)
Circuit breaker
StecaGrid 4611_2 2.5 mm² 56 W
B25
4.0 mm² 35 W
StecaGrid 5011_2 2.5 mm² 64 W
B25
4.0 mm² 40 W
Inverter, 3-phase
Cable cross section
AC cable
Power loss
(with 10 m cable length)
Circuit breaker
StecaGrid 3213 2.5 mm² 4 W
B16
4.0 mm² 3 W
StecaGrid 4013 2.5 mm² 7 W
B16
4.0 mm² 4 W
StecaGrid 5013
2.5 mm²
11 W
B16
4.0 mm² 7 W
StecaGrid 6013 2.5 mm² 14 W
B16
4.0 mm² 8 W
5.3.3 Assembling the AC plug
NOTE
If the instructions of the plug manufacturer are not followed when connecting
the AC plug, the cable and the device may be damaged.
►
Protect plug from bending loads.
►
Do not use plug connector for interruption of current.
