Functional Description Special Functions
Source analog parameter
setting (An.53)
This parameter determines whether the analog parameter setting occurs via the motor-
poti or the aux-function.
an.53 Function
0AUX
1 Motor-poti function
The Bus-address of the parameter, that is to be adjusted in analog mode, is adjusted
here (see Chapter 5). Following parameters can be adjusted:
uF.1 / 7
cn. 4 / 5 / 6
An.32 / 37 / 42 / 48
LE.0 / 1 / 2 / 3 / 4 / 5 / 6 / 7
cS.6 / 9
Ec.4 / 14
In case an invalid parameter address is selected, the message „IdAtA“ (or „data inva-
lid“ at COMBIVIS) is output and the setting is ignored.
Defines the parameter value, that adjusts itself at 0 % analog parameter setting. The
parameter value must be entered with the internal standardization of the target parameter.
Desired value of target parameter
Value to be adjusted = --------------------------------------------------------
Resolution of target parameter
Defines the parameter value, that adjusts itself at 100 % analog parameter setting.
The parameter value must be entered with the internal standardization of the target
parameter.
The analog parameter setting is not programmable. If a programmable parameter is
adjusted as target parameter, then the target set adjusted in fr.9 is valid.
Target analog parameter setting
(An.54)
Offset analog parameter setting
(An.55)
Maximal value analog
parameter setting (An.56)
Param. Adr.
min
max
default
ENTER
PROG.
R/W
Step
Used Parameters
An.53 0A35h ✔ - ✔ 0110-
An.54 0A36h ✔ - ✔ -1: oFF 7FFFh 0001h -1: oFF -
An.55 0A37h ✔ - ✔ -2147483648 2147483647 1 0 -
An.55 0A37h ✔ - ✔ -2147483648 2147483647 1 0 -
An.56 0A38h ✔ - ✔ -2147483648 2147483647 1 0 -
6.9.10 Analog setting of
parameter values
With this function it is possible to preset parameter values analog. The AUX-function or
the motor-poti function can be adjusted as source.
