Functional Description Encoder Interface
Parameter Addr.
min
max
default
[?] Notes
Ec.0 encoder 1 interface 1000 x – x -127 127 1 GBK - GBK=encoder Id
Ec.1 encoder 1 (inc/r) 1001 x – – 1 16383 1 GBK - GBK=encoder Id
Ec.2 Absolute position 1 1002 ja – – 0 65535 1 0 - only F5-S
Ec.3 time 1 for speed calc. 1003 x – – 0 9 1 3 - -
Ec.4 gear 1 numerator 1004 x – – -10000 10000 1 1000 - -
Ec.5 gear 1 determinator 1005 x – – 1 10000 1 1000 - -
Ec.6 enc.1 rotation 1006 x – – 0 23 1 0 - -
Ec.7 enc.1 trigger 1007 x – – 0 13 1 GBK - GBK=encoder Id
Ec.10encoder 2 interface 100A x – x -127 127 1 GBK - GBK=encoder Id
Ec.11encoder 2 (inc/r) 100B x – – 1 16383 1 GBK - GBK=encoder Id
Ec.12Absolute position 2 100C ja – – 0 65535 1 0 - only F5-S
Ec.13time 2 for speed calc. 100D x – – 0 9 1 3 - -
Ec.14gear 2 numerator 100E x – – -10000 10000 1 1000 - -
Ec.15gear 2 determinator 100F x – – 1 10000 1 1000 - -
Ec.16enc.2 rotation 1010 x – – 0 23 1 0 - -
Ec.17enc.2 trigger 1011 x – – 0 13 1 2 - GBK=encoder Id
Ec.20enc.2 operating mode 1014 x – – 0 1 1 GBK - -
Ec.21SSI multiturn resolution 1015 x – – 0 13 12 1 - -
Ec.22SSI clock frq. sel. 1016 x – – 0 1 0 1 - -
Ec.23SSI data code 1017 x – – 0 1 1 1 - -
Ec.25nominal tacho speed 1019 x – – 1 16000 1500 1 rpm -
Ec.27operation mode output 101B x – x 0 47 1 0 - -
Ec.31Absolute position channel 1 101F – – – 0 255 1 0 - -
Ec.32Absolute position channel 2 1020 – – – 0 255 1 0 - -
Ec.33System offset channel 1 1021 ja – ja -2
31
2
31
-1 1 0 Ink only F5-M/S
Ec.34System offset channel 2 1022 ja – ja -2
31
2
31
-1 1 0 Ink only F5-M/S
Ec.36encoder 1 typ 1024 – – – 0 255 1 0 - -
Ec.37encoder 1 state 1025 – – – 0 255 1 0 - -
Ec.38encoder 1 r/w 1026 – – – 0 2 1 0 - -
