KEB COMBIVERT F5 BASIC User Manual

Parameter
5 1
KEB COMBIVERT F5-G / B
8
Name: Basis
14.06.02
Chapter Section Page Date
© KEB Antriebstechnik, 2002
All Rights reserved
Parameter Adr. Control Properties min. max. Step default [?] see on Page
an54 an. para setting dest. 0A36 - - G M S A - - E - -1 7FFFH 1 -1 hex 6.9.34
an55 an. para setting offset 0A37 - - G M S A - - - - -2^31 2^31-1 1 0 - 6.9.34
an56 an. para set. max. value 0A38 - - G M S A - - - - -2^31 2^31-1 1 0 - 6.9.34
cn 0 PID reference source 0700 B g G M S A - P - - 0 4 1 0 - 6.12.5
cn 1 PID abs. reference 0701 B g G M S A - P - - -400,0 400,0 0,1 0,0 % 6.12.5
cn 2 PID act. value src. 0702 B g G M S A - P - - 0 7 1 0 - 6.12.6
cn 3 PID abs. act. value 0703 B g G M S A - - - - -400,0 400,0 0,1 0,0 % 6.12.6
cn 4 PID kp 0704 B g G M S A - P - - 0,00 250,00 0,01 0,00 - 6.12.3
cn 5 PID ki 0705 B g G M S A - P - - 0,000 30,000 0,001 0,000 - 6.12.3
cn 6 PID kd 0706 B g G M S A - P - - 0,00 250,00 0,01 0,00 - 6.12.3
cn 7 PID pos. limit 0707 B g G M S A - P - - -400,0 400,0 0,1 400,0 % 6.12.3
cn 8 PID neg. limit 0708 B g G M S A - P - - -400,0 400,0 0,1 -400,0 % 6.12.3
cn 9 PID fading time 07 09 B g G M S A - P - - -0,01 300,00 0,01 0,00 s 6.12.3
cn10 PID reset condition 070A B g G M S A - P - - 0 2 1 0 - 6.12.4
cn11 PID reset inp. sel. 070B B g G M S A - - E - 0 4095 1 0 - 6.12.4, 6.3.8
cn12 I reset inp. sel. 070C B g G M S A - - E - 0 4095 1 0 - 6.12.4, 6.3.8
cn13 fade in reset inp. sel. 070D B g G M S A - - E - 0 4095 1 0 - 6.12.4, 6.3.8
cn14 PID out freq at 100% 070E B g G - - A - P - V -400 400 0,0125 0 Hz 6.12.4
cs 0 speed control config. 0F 00 B g G ----P--0 63 1 0 - 6.6.11
cs 1 act. source 0F01 - - G ----P--0 2 1 2 - 6.6.14; 6.11.3, 6.11.13, 6.9.20
cs 4 speed ctrl. freq. limit 0F04 B g G - - A - P - V 0 200 0,0125 25 Hz
cs 6 KP speed 0F06 B g G - - A - P - - 0 32767 1 50 - 6.6.14
cs 9 KI speed 0F09 B g G - - A - P - - 0 32767 1 500 - 6.6.14
di 0 PNP / NPN selection 0B00 - g G M S A - - E - 0 SHR 1 0 - 6.3.3
di 1 select signal source 0B01 B g G M S A - - E - 0 4095 1 0 - 6.3.4
di 2 digital input setting 0B02 B g G M S A - - E - 0 4095 1 0 - 6.3.4
di 3 digital noise filter 0B03 B g G M S A - - E - 0 127 1 0 ms 6.3.5
di 4 input logic 0B04 B g G M S A - - E - 0 4095 1 0 - 6.3.5
di 5 input trigger 0B05 B g G M S A - - E - 0 4095 1 0 - 6.3.5
di 6 select strobe source 0B06 B g G M S A - - E - 0 4095 1 0 - 6.3.6
di 7 strobe mode 0B07 B g G M S A - - E - 0 2 1 0 - 6.3.7
di 8 input strobe dependence 0B08 B g G M S A - - E - 0 4095 1 0 - 6.3.6
di 9 reset input selection 0B09 B g G M S A - - E - 0 4095 1 3 - 6.3.8
di 10 reset input slope sel. 0B0A B g G M S A - - E - 0 4095 1 3 - 6.3.8
di 11 I1 functions 0B0B B g G M S A - - E - 0 H’ 3FFFFFFF 1 1 hex 6.3.9
di 12 I2 functions 0B0C B g G M S A - - E - 0 H’ 3FFFFFFF 1 2 hex 6.3.9
di 13 I3 functions 0B0D B g G M S A - - E - 0 H’ 3FFFFFFF 1 8192 hex 6.3.9
di 14 I4 functions 0B0E B g G -----E-0 H’ 3FFFFFFF 1 512 hex 6.3.9
di 15 IA functions 0B0F B g G M S A - - E - 0 H’ 3FFFFFFF 1 0 hex 6.3.9
di 16 IB functions 0B10 B g G M S A - - E - 0 H’ 3FFFFFFF 1 0 hex 6.3.9
di 17 IC functions 0B11 B g G M S A - - E - 0 H’ 3FFFFFFF 1 0 hex 6.3.9
di 18 ID functions 0B12 B g G M S A - - E - 0 H’ 3FFFFFFF 1 0 hex 6.3.9
di 19 F functions 0B13 B g G M S - - - E - 0 H’ 3FFFFFFF 1 32 hex 6.3.9
di 20 R functions 0B14 B g G M S - - - E - 0 H’ 3FFFFFFF 1 64 hex 6.3.9
di 21 RST functions 0B15 B g G M S - - - E - 0 H’ 3FFFFFFF 1 128 hex 6.3.9
di 22 ST functions 0B16 B g G M S A - - E - 0 H’ 3FFFFFFF 1 128 hex 6.3.9
do 0 condition 0 0C00 B g G M S A - P E - 0 68 1 20 - 6.3.13
do 1 condition 1 0C01 B g G M S A - P E - 0 68 1 3 - 6.3.13
do 2 condition 2 0C02 B g G M S A - P E - 0 68 1 4 - 6.3.13
do 3 condition 3 0C03 B g G ----PE- 0 68 1 27 - 6.3.13
do 4 condition 4 0C04 B g G M S A - P E - 0 68 1 0 - 6.3.13
do 5 condition 5 0C05 B g G M S A - P E - 0 68 1 0 - 6.3.13
do 6 condition 6 0C06 B g G M S A - P E - 0 68 1 0 - 6.3.13
do 7 condition 7 0C07 B g G M S A - P E - 0 68 1 0 - 6.3.13
do 8 inv. cond. for flag 0 0C08 B g G M S A - P E - 0 255 1 0 - 6.3.16
do 9 inv. cond. for flag 1 0C09 B g G M S A - P E - 0 255 1 0 - 6.3.16
do10 inv. cond. for flag 2 0C0A B g G M S A - P E - 0 255 1 0 - 6.3.16
do11 inv. cond. for flag 3 0C0B B g G M S A - P E - 0 255 1 0 - 6.3.16
do12 inv. cond. for flag 4 0C0C B g G M S A - P E - 0 255 1 0 - 6.3.16
do13 inv. cond. for flag 5 0C0D B g G M S A - P E - 0 255 1 0 - 6.3.16
do14 inv. cond. for flag 6 0C0E B g G M S A - P E - 0 255 1 0 - 6.3.16
do15 inv. cond. for flag 7 0C0F B g G M S A - P E - 0 255 1 0 - 6.3.16
do16 cond. select. for flag 0 0C10 B g G M S A - P E - 0 255 1 1 - 6.3.16
do17 cond. select. for flag 1 0C11 B g G M S A - P E - 0 255 1 2 - 6.3.16
do18 cond. select. for flag 2 0C12 B g G M S A - P E - 0 255 1 4 - 6.3.16
do19 cond. select. for flag 3 0C13 B g G M S A - P E - 0 255 1 8 - 6.3.16
do20 cond. select. for flag 4 0C14 B g G M S A - P E - 0 255 1 16 - 6.3.16
do21 cond. select. for flag 5 0C15 B g G M S A - P E - 0 255 1 32 - 6.3.16
do22 cond. select. for flag 6 0C16 B g G M S A - P E - 0 255 1 64 - 6.3.16
do23 cond. select. for flag 7 0C17 B g G M S A - P E - 0 255 1 128 - 6.3.16
do24 AND conn. for flags 0C18 B g G M S A - P E - 0 255 1 0 - 6.3.16
do25 inv. flags for O1 0C19 - g G M S A - P E - 0 255 1 0 - 6.3.17
do26 inv. flags for O2 0C1A - g G M S A - P E - 0 255 1 0 - 6.3.17
do27 inv. flags for R1 0C1B B g G M S A - P E - 0 255 1 0 - 6.3.17
do28 inv. flags for R2 0C1C B g G M S - - P E - 0 255 1 0 - 6.3.17
do29 inv. flags for OA 0C1D B g G M S A - P E - 0 255 1 0 - 6.3.17
do30 inv. flags for OB 0C1E B g G M S A - P E - 0 255 1 0 - 6.3.17
