KEB COMBIVERT F5 BASIC User Manual

Parameter
5
19
KEB COMBIVERT F5-G / B
Name: Basis
14.06.02
Section PageDate
© KEB Antriebstechnik, 2002
All Rights reserved
Chapter
Parameter Adr. Control Properties min. max. Step default [?] see on Page
5
do31 inv. flags for OC 0C1F B g G M S A - P E - 0 255 1 0 - 6.3.17
do32 inv. flags for OD 0C20 B g G M S A - P E - 0 255 1 0 - 6.3.17
do33 flag select. for O1 0C21 - g G M S A - P E - 0 255 1 1 - 6.3.17
do34 flag select. forO2 0C22 - g G M S A - P E - 0 255 1 2 - 6.3.17
do35 flag select. for R1 0C23 B g G M S A - P E - 0 255 1 4 - 6.3.17
do36 flag select. for R2 0C24 B g G M S - - P E - 0 255 1 8 - 6.3.17
do37 flag select. for OA 0C25 B g G M S A - P E - 0 255 1 16 - 6.3.17
do38 flag select. for OB 0C26 B g G M S A - P E - 0 255 1 32 - 6.3.17
do39 flag select. for OC 0C27 B g G M S A - P E - 0 255 1 64 - 6.3.17
do40 flag select. for OD 0C28 B g G M S A - P E - 0 255 1 128 - 6.3.17
do41 AND conn. for outputs 0C29 B g G M S A - P E - 0 255 1 0 - 6.3.17
do42 inverted outputs 0C2A B g G M S A - P E - 0 255 1 0 - 6.3.18
do43 cond. 0 filter time 0C2B - - G M S A - P - - 0 1000 1 0 ms 6.3.12
do44 cond. 1 filter time 0C2C - - G M S A - P - - 0 1000 1 0 ms 6.3.12
dr 0 DASM rated current 0600 B g G M - A - P - - 0,0 710 0,1 LTK A 6.6.3
dr 1 DASM rated speed 06 01 B g G M - A - P - - 0 64000 1 LTK rpm 6.6.3
dr 2 DASM rated voltage 0602 B g G M - A - P - - 120 500 1 LTK V 6.6.3
dr 3 DASM rated power 06 03 - - G M - A - P - - 0,35 400,00 0,01 LTK kW 6.6.3
dr 4 DASM rated cos(phi) 0604 B g G M - A - P - - 0,50 1,00 0,01 LTK - 6.6.3
dr 5 DASM rated frequency 0605 B g G M - A - P - - 0,0 1600,0 0,1 LTK Hz 6.6.3
dr 6 DASM stator resistance 0606 B g G M - A - P - - 0,000 50,000 0,001 LTK Ohm 6.6.4
dr 9 breakdown factor 06 09 B g G - - A - P - - 0,5 4,0 0,1 2,5 -
dr 11 motorprotection mode 060B B g G M - A - P - - 0 1 1 1 - 6.7.16
dr 12 motorprot. rated current 060C B g G M - A - P - - 0,0 710,0 0,1 LTK A 6.7.16
ec 0 encoder 1 interface 1000 - - G M S A - - X - -127 127 1 GBK - 6.10.10
ec 1 encoder 1 (inc/r) 1001 - - G M S A - - - - GBK GBK 1 GBK inc 6.10.10
ec 3 time 1 for speed calc. 1003 - - G M S A - - - - 0 9 1 3 - 6.10.10
ec 4 gear 1 numerator 1004 - - G M S A - - - - -10000 10000 1 1000 - 6.10.11
ec 5 gear 1 determinator 1005 - - G M S A - - - - 1 10000 1 1000 - 6.10.11
ec 6 enc.1 rotation 1006 - - G M S A - - - - 0 19 1 0 - 6.10.11
ec 7 enc.1 trigger 1007 - - G M S - - - - - GBK GBK 1 GBK - 6.10.11
ec10 encoder 2 interface 100A - - G M S A - - X - -127 127 1 GBK - 6.10.6, 6.10.10
ec11 encoder 2 (inc/r) 100B - - G M S A - - - - GBK GBK 1 GBK inc 6.10.10
ec13 time 2 for speed calc. 100D - - G M S A - - - - 0 9 1 3 - 6.10.10
ec14 gear 2 numerator 100E - - G M S A - - - - -10000 10000 1 1000 - 6.10.11
ec15 gear 2 determinator 100F - - G M S A - - - - 1 10000 1 1000 - 6.10.11
ec16 enc.2 rotation 1010 - - G M S A - - - - 0 19 1 0 - 6.10.11
ec17 enc.2 trigger 1011 - - G M S - - - - - GBK GBK 1 GBK - 6.10.11
ec20 enc.2 operating mode 10 14 - - G M S A - - - - 0 1 1 0 - 6.10.7
ec21 SSI multiturn res. 1015 - - G M S - - - - - 0 13 1 12 - 6.10.13
ec22 SSI clock frq. sel. 1016 - - G M S - - - - - 0 1 1 0 - 6.10.13
ec23 SSI data code 1017 - - G M S - - - - - 0 1 1 1 - 6.10.13
ec25 nominal tacho speed 1019 - - G M S - - - - - 1 16000 1 1500 rpm 6.10.13
ec27 operation mode output 10 1A - - G M S - - - E - 0 47 1 0 - 6.10.12
ec31 abs. position ch1 101F - - G M S A - - - - -2^31 2^31-1 1 0 inc 6.10.13
ec32 abs. position ch2 1020 - - G M S - - - - - -2^31 2^31-1 1 0 inc 6.10.13
ec36 enc.1 encoder type 1024 - - G M S - - - - - 0 255 1 0 - 6.10.13
ec37 enc.1 encoder status 1025 - - G M S - - - - - 0 255 1 0 - 6.10.13
ec38 enc.1 encoder r/w 1026 - - G M S - - - E - 0 2 1 0 - 6.10.13
fr 1 copy parameter set 0901 B g G M S A - P E - -4 7 1 0 - 6.8.4
fr 2 parameter set source 0902 B g G M S A - - E - 0 5 1 0 - 6.8.5
fr 3 parameter set lock 0903 B g G M S A - - E - 0 255 1 0 - 6.8.8
fr 4 parameter set setting 0904 B g G M S A - - E - 0 7 1 0 - 6.8.5
fr 5 set activation delay 0905 B g G M S A - P - - 0,00 2,55 0,01 0,00 s 6.8.8, 6.9.31
fr 6 set deactivation delay 0906 B g G M S A - P - - 0,00 2,55 0,01 0,00 s 6.8.8, 6.9.31
fr 7 paraset input sel. 0907 B g G M S A - - E - 0 4095 1 0 - 6.8.6, 6.3.8
fr 8 motor set classification 0908 B g G M - A - P - - 0 7 1 0 - 6.7.14
fr 9 bus parameter set 0909 B g G M S A - - - - -1 7 1 0 - 6.8.4
fr 10 load mot.dependent para. 090A - - G ----PE-3 3 1 3 - 6.6.6
fr 11 reset set input sel. 090B B g G M S A - - E - 0 4095 1 0 - 6.8.7, 6.3.8
in 0 inverter type 0E00 B g G M S A R - - - LTK LTK 1 LTK hex 6.1.19
in 1 rated inverter current 0E01 B g G M S A R - - - LTK LTK 0,1 LTK A 6.1.19
in 3 max. carrier frequency 0E03 B g G M S A R - - - LTK LTK 1 LTK - 6.1.20
in 4 rated carrier frequency 0E04 B g G M S A R - - - LTK LTK 1 LTK - 6.1.20
in 6 software version 0E06 B g G M S A R - - - SW SW 0,01 SW - 6.1.20
in 7 software date 0E07 B g G M S A R - - - SW SW 0,1 SW - 6.1.20
in 8 software version p. unit 0E08 - g ----R---LTK LTK 1 LTK -
in9software date p. unit 0E09-g----R---LTK LTK 1 LTK -
in 10 serial no. (date) 0E0A B g G M S A R - - - 0 65535 1 0 - 6.1.21
in 11 serial no. (count) 0E0B B g G M S A R - - - 0 65535 1 0 - 6.1.21
in 12 serial no. (AB-no. high) 0E0C B g G M S A R - - - 0 65535 1 0 - 6.1.21
in 13 serial no. (AB-no. low) 0E0D B g G M S A R - - - 0 65535 1 0 - 6.1.21
in 14 customer no. high 0E0E B g G M S A R - - - 0 65535 1 0 - 6.1.21
in 15 customer no. low 0E0F B g G M S A R - - - 0 65535 1 0 - 6.1.21
in 16 QS no. 0E10 B g G M S A R - - - 0 65535 1 0 - 6.1.21
in 17 temp.- mode 0E11 - - G M S A R - - - LTK LTK 1 LTK - 6.1.21
in 22 user parameter 1 0E16 B g G M S A - - - - 0 65535 1 0 - 6.1.21
