GB - 7
Preface
This accompanying instruction manual contains only information for the installa-
tion and connection of the IO-Link control of the KEB COMBIVERT G6.
Further parts of the installation manual are required depending on the ordered
type:
• Connection and adjustments of the power unit
• Safety function STO
• Safe digital output for f=0Hz
A manual with general safety requirements and EMC conform installation is
available under www.keb.de.
1.7 Part code
xx G6 x x x - x x x x
Cooling (not valid for customer-/special version)
0 Air-cooling (housing C, D, E); air-cooling/at rear (housing A, B)
1 Flat rear
Control/keyboard/display (not valid for customer-/special version)
0 Open-loop without keyboard/display A like 0 on ASCL hardware
1 Open-loop with keyboard/display B like 1 on ASCL hardware
2 SCL without keyboard/display
3 SCL with keyboard/display
4 ASCL without keyboard/display
5 ASCL with keyboard/display
Switching frequency; short time current limit; overcurrent cut-off
(not valid at customer/special version)
0 2 kHz 125 % 150 % 1 4 kHz 125 % 150 %
2 8 kHz 125 % 150 % 3 16 kHz 125 % 150 %
4 2 kHz 150 % 180 % 5 4 kHz 150 % 180 %
6 8 kHz 150 % 180 % 7 16 kHz 150 % 180 %
8 2 kHz 180 % 216 % 9 4 kHz 180 % 216 %
A 8 kHz 180 % 216 % B 2 kHz 180 % 216 %
Voltage, connection
0 1-phase 230 V AC/DC 3 3-phase 400 V AC/DC
1 3-phase 230 V AC/DC 5 400 V DC
2 1/3-phase 230 V AC/DC 6 1-phase 230 V AC
A-Z Customer-/special version (rmware and download)
Housing type A, B, C, D, E
Variants
further on next side
