33
Parameter conguration
ServoOne User Manual SERCOS II and III
ID no.: 1108.26B.3-00 Date: 04/2020
Parameter conguration
The real-time control bits and real-time status bits can be congured in phases 2, 3
and 4.
The assignment parameters contain the number of the parameter to be congured for
the related real-time bit.
During conguration it is to be noted that the bit number must be assigned rst
(S-0-0413, S-0-0414, S-0-0415, S-0-0416) before a corresponding IDN is assigned as
the real-time bit (S-0-0301, S-0-0303, S-0-0305, S-0-0307).
6.4.2 Conguration of real-time bits, SERCOS III
y S-0-1050.x.20 "IDN – assignment real-time bit": IDN of the parameter
that is to be assigned to the related real-time bit.
y S-0-1050.x.21 "Bit – assignment real-time bit": Denition of which
bit number of the parameter assigned is to be represented.
6.5 Signal control word and signal status word
6.5.1 Signal control word (S-0-0145)
Signals can be transferred from the controller to the drive in real-time in the signal
control word S-0-0145. The signal control word can be congured for the cyclic
transfer in the master data telegram (MDT). The signal control word is congured in
phase 2 and is activated on the transition to phase 3. An erroneous conguration will
result in a device error and it will not be possible to switch to phase 3. The conguration
parameters for the signal control word are described in the following table.
S-0-0027 Conguration list for signal control word
This list contains all parameter numbers that are contained in the signal control word.
The sequence of the parameter numbers in the list denes the signicance of the bits
in the signal status word. The rst parameter in the list denes bit 0, the last parameter
number bit 15. The parameter S-0-0328 denes the bit number from the related
parameter that is to be given in the signal status word.
S-0-0329 Bit number allocation word for signal control word
Table 6.8 Conguration parameters for the signal control word
S-0-0027 Conguration list for signal control word
The bit numbers for the parameters from S-0-0027 copied to the signal control word
(S-0-0145) are programmed in this conguration list. The sequence of the bit numbers
in the list is that same as the sequence of the signals in the signal control word.
Table 6.8 Conguration parameters for the signal control word
The list of congurable parameters for the real-time status bits P3002 applies for the
conguration of the signal status word.
6.5.2 Signal status word (S-0-0144)
The drive status congured by the user can be represented in the signal status word
S-0-0144. The signal status word can be congured for the cyclic transfer in the drive
telegram (AT). The signal status word is congured in phase 2 and is activated on the
transition to phase 3. An erroneous conguration will result in a device error and it will
not be possible to switch to phase 3. The conguration parameters for the signal status
word are described in the following table.
S-0-0026 Conguration list for signal status word
This list contains all parameter numbers that are contained in the signal status word.
The sequence of the parameter numbers in the list denes the signicance of the bits
in the signal status word. The rst parameter in the list denes bit 0, the last parameter
number bit 15. The parameter S-0-0328 denes the bit number from the related
parameter that is to be given in the signal status word.
S-0-0328 Signal status word bit number assignment list
The bit numbers for the parameters from S-0-0026 copied to the signal status word
(S-0-0144) are programmed in this conguration list. The sequence of the bit numbers
in the list is that same as the sequence of the signals in the signal status word.
Table 6.9 Conguration parameters for the signal status word
The list of congurable parameters for the real-time status bits P3002 applies for the
conguration of the signal status word.
